- 100克螺杆给袋包装机
- 产品型号: C-LG100
技术参数
Technical Parameters
计量范围:1 - 500g
Measuring Scope
包装速度:20 - 30 袋 /分钟
Packaging speed:
外型尺寸:980*650*1800mm
External dimension
工作气压:0.6-0.8MPa/0.83m³/min
Working air pressure
整机重量:160kg
Operating weight
总 功 率:AC~220V/ 1.25kw
Total power
包装精度:±1g
Packaging accuracy
料仓容量:16kg
Silo capacity
袋仓容量 450 个-(袋子厚度 10 丝)
Bag bin capacity 450 - (bag thickness 10 silk)
打包尺寸/重量:1100*750*1950mm/265kg
Package size/weight
- 产品描述
- 产品特点
- 操作视频
- 安装使用
- 维修售后
- 功能讲解
- 客户现场
1、本设备搭配完美的粉剂立螺杆下料器,可实现螺杆头部伸入袋口处灌粉,有效防止扬尘,并提高设备运行速度
The equipment is equipped with a perfect powder vertical screw feeder, which can realize the filling of powder at the place where the screw head extends into the bag mouth, effectively prevent dust, and improve the operation speed of the equipment
2、适用于食品、医药、化工、化妆品、粉剂农药行业中粉剂物品的计量包装。
The machine is suitable for the food, medicine, chemical industry, cosmetics industry of powder of measurement packing.
3、触摸屏操作,PLC 控制,性能稳定、调整方便、检测准确。PID调节,保证将温度的误差范围控制在1℃以内。
The touch screen operation, PLC control, drive stepper motor to control the bag length,stable performance,easy to adjust and accurate detection.Choose the intelligent temperature controller and PID control to ensure the error range of temperature controlled within 1 degree Centigrade.
4、适用多种尺寸袋子,从5*7CM到18*26CM袋子规格范围内都适用,可以兼容拉链袋,自立袋,等多种样式的袋子。
Multiple bag sizes, from 5*7CM to 18 * 26CM bags, can be compatible with zip bags, self-supporting bags, and other styles of bags.
